A Successful Healthy Childbirth in a Case of Total Globozoospermia with Oocyte Activation by Calcium Ionophore

Authors
Nilay Karaca 1
Yasam Akpak 2
Serkan Oral 3
Tugce Durmus 1
Rabiye Yilmaz 1
1 TDV 29 Mayis Hospital, Department of Assisted Reproduction, Istanbul, Turkey
2 Ankara Mevki Military Hospital, Department of Obstetrics and Gynecology, Ankara, Turkey
3 LIV Hospital, Department of Assisted Reproduction, Istanbul, Turkey
Abstract
Background: Globozoospermia is a rare (incidence of 0.1% among andrological patients) and poorly understood condition, but a severe disorder in male infertility. This case report detailed the course of treatment and protocol of a patient with type 1 globozoospermia using Intracytoplasmic Sperm Injection (ICSI) and oocyte activation by calcium ionophore, which yielded conception and birth of a healthy baby after six previous unsuccessful attempts, using ICSI alone. Case Presentation: A 39-year-old male with normal findings on routine examination presented to TDV 29 Mayis Hospital, Assisted Reproduction Unit (ART) with his 37-year-old wife. Her examination was also within normal limits and ovulatory cycle was regular. The male’s diagnostic screening revealed normal karyotype (46, XY) and no Y-microdeletion. However, the spermogram was abnormal; sperm count of 14 million/ml with 35% active motility and 100% morphologically abnormal sperm, indicating globozoospermia. Ovarian stimulation was provided using classic long down-regulation protocol and 13 MII oocytes were collected. Next, calcium ionophore was applied following the ICSI procedure to improve the chances for fertilization. The case report compared quantitative procedural and diagnostic screening data, and fertilization rates. On day 5, two grade 1 blastcysts out of 5 embryos were transferred, yielding positive beta-human chorionic gonadotropin (beta hCG), and ultimately a healthy delivery. Conclusion: ICSI with assisted oocyte activation by calcium ionophore may overcome male infertility where there is total globozoospermia.
Keywords
Calcium ionophore
Globozoospermia
Intracytoplasmic sperm injection (ICSI)
Morphologically abnormal sperm
  1. Thonneau P, Marchand S, Tallec A, Ferial ML, Ducot B, Lansac J, et al. Incidence and main causes of infertility in a resident population (1,850,000) of three French regions (1988-1989). Hum Reprod. 1991;6(6):811-6.
  2. World Health Organization. WHO manual for the standardised investigation and diagnosis of the infertile male. Cambridge: Cambridge University Press; 2000. 5 p.
  3. Anton-Lamprecht I, Kotzur B, Schopf E. Round-headed human spermatozoa. Fertil Steril. 1976;27(6):685-93.
  4. Xu M, Xiao J, Chen J, Li J, Yin L, Zhu H, et al. Identification and characterization of a novel human testis-specific Golgi protein, NYD-SP12. Mol Hum Reprod. 2003;9(1):9-17.
  5. Koscinski I, Elinati E, Fossard C, Redin C, Muller J, Velez de la Calle J, et al. DPY19L2 deletion as a major cause of globozoospermia. Am J Hum Genet. 2011;88(3):344-50.
  6. Liu G, Shi QW, Lu GX. A newly discovered mutation in PICK1 in a human with globozoospermia. Asian J Androl. 2010;12(4):556-60.
  7. Dam AH, Koscinski I, Kremer JA, Moutou C, Jaeger AS, Oudakker AR, et al. Homozygous mutation in SPATA16 is associated with male infertility in human globozoospermia. Am J Hum Genet. 2007;81(4):813-20.
  8. Lundin K, Sjogren A, Nilsson L, Hamberger L. Fertilization and pregnancy after intracytoplasmic microinjection of acrosomeless spermatozoa. Fertil Steril. 1994;62(6):1266-7.
  9. Kilani Z, Ismail R, Ghunaim S, Mohamed H, Hughes D, Brewis I, et al. Evaluation and treatment of familial globozoospermia in five brothers. Fertil Steril. 2004;82(5):1436-9.
  10. Egashira A, Murakami M, Haigo K, Horiuchi T, Kuramoto T. A successful pregnancy and live birth after intracytoplasmic sperm injection with globozoospermic sperm and electrical oocyte activation. Fertil Steril. 2009;92(6):2037.
  11. Grasa P, Coward K, Young C, Parrington J. The pattern of localization of the putative oocyte activation factor, phospholipase Czeta, in uncapacitated, capacitated, and ionophore-treated human spermatozoa. Hum Reprod. 2008;23(11):2513-22.
  12. Harbuz R, Zouari R, Pierre V, Ben Khelifa M, Kharouf M, Coutton C, et al. A recurrent deletion of DPY19L2 causes infertility in man by blocking sperm head elongation and acrosome formation. Am J Hum Genet. 2011;88(3):351-61.
  13. Dam AH, Feenstra I, Westphal JR, Ramos L, van Golde RJ, Kremer JA. Globozoospermia revisited. Hum Reprod Update. 2007;13(1):63-75.
  14. Yao R, Ito C, Natsume Y, Sugitani Y, Yamanaka H, Kuretake S, et al. Lack of acrosome formation in mice lacking a Golgi protein, GOPC. Proc Natl Acad Sci U S A. 2002;99(17):11211-6.
  15. Kierszenbaum AL, Tres LL, Rivkin E, Kang-Decker N, van Deursen JM. The acroplaxome is the docking site of Golgi-derived myosin Va/Rab27a/b- containing proacrosomal vesicles in wild-type and Hrb mutant mouse spermatids. Biol Reprod. 2004;70(5):1400-10.
  16. Kashir J, Heindryckx B, Jones C, De Sutter P, Parrington J, Coward K. Oocyte activation, phospholipase C zeta and human infertility. Hum Reprod Update. 2010;16(6):690-703.
  17. Sermondade N, Hafhouf E, Dupont C, Bechoua S, Palacios C, Eustache F, et al. Successful childbirth after intracytoplasmic morphologically selected sperm injection without assisted oocyte activation in a patient with globozoospermia. Hum Reprod. 2011;26(11):2944-9.
  18. Dirican EK, Isik A, Vicdan K, Sozen E, Suludere Z. Clinical pregnancies and livebirths achieved by intracytoplasmic injection of round headed acrosomeless spermatozoa with and without oocyte activation in familial globozoospermia: case report. Asian J Androl. 2008;10(2):332-6.
  19. Heindryckx B, Van der Elst J, De Sutter P, Dhont M. Treatment option for sperm- or oocyte-related fertilization failure: assisted oocyte activation following diagnostic heterologous ICSI. Hum Reprod. 2005;20(8):2237-41.
  20. Vanden Meerschaut F, Leybaert L, Nikiforaki D, Qian C, Heindryckx B, De Sutter P. Diagnostic and prognostic value of calcium oscillatory pattern analysis for patients with ICSI fertilization failure. Hum Reprod. 2013;28(1):87-98.
  21. Kuentz P, Vanden Meerschaut F, Elinati E, Nasr-Esfahani MH, Gurgan T, Iqbal N, et al. Assisted oocyte activation overcomes fertilization failure in globozoospermic patients regardless of the DPY19L2 status. Hum Reprod. 2013;28(4):1054-61.
  22. Versieren K, Heindryckx B, Lierman S, Gerris J, De Sutter P. Developmental competence of parthenogenetic mouse and human embryos after chemical or electrical activation. Reprod Biomed Online. 2010;21(6):769-75.
  23. Perrin A, Nguyen MH, Bujan L, Vialard F, Amice V, Gueganic N, et al. DNA fragmentation is higher in spermatozoa with chromosomally unbalanced content in men with a structural chromosomal rearrangement. Andrology. 2013;1(4):632-8.
  24. Baccetti B, Renieri T, Rosati F, Selmi MG, Casanova S. Further observations on the morphogenesis of the round headed human spermatozoa. Andrologia. 1977;9(3):255-64.
  25. Larson KL, Brannian JD, Singh NP, Burbach JA, Jost LK, Hansen KP, et al. Chromatin structure in globozoospermia: a case report. J Androl. 2001;22(3):424-31.
  26. Vicari E, Perdichizzi A, De Palma A, Burrello N, D'Agata R, Calogero AE. Globozoospermia is associated with chromatin structure abnormalities: case report. Hum Reprod. 2002;17(8):2128-33.
  27. Perrin A, Louanjli N, Ziane Y, Louanjli T, Le Roy C, Gueganic N, et al. Study of aneuploidy and DNA fragmentation in gametes of patients with severe teratozoospermia. Reprod Biomed Online. 2011;22(2):148-54.
Journal of Reproduction & Infertility
Volume 16, Issue 2
Spring 2015
Pages 116-120
