The Window of Implantation Is Closed by Estrogen via Insulin-Like Growth Factor 1 Pathway

Authors
1 Laboratory of Animal Morphology, Division of Biofunctional Development, Graduate School of Bioagricultural Sciences, Nagoya University, Nagoya, Japan
2 Laboratory of Animal Morphology, Division of Biofunctional Development, Graduate School of Bioagricultural Sciences, Nagoya University, Nagoya, Japan; Division of Transgenic Animal Science, Advanced Science Research Center, Kanaza
3 Research and Education Center for Prevention of Global Infectious Diseases of Animals, Tokyo University of Agriculture and Technology, Tokyo, Japan
Abstract
Background: The opening and closing of the implantation window is important for successful pregnancy in eutherians. The recent study demonstrated that the window of uterine receptivity was prepared by the sole action of progesterone in mice, but the mechanism to close the window remained to be elucidated. Methods: The pregnant mice were ovariectomized on the evening on the third day of pregnancy with a single injection of medroxyprogesterone acetate to induce delayed implantation (DI). Several treatments were applied to DI mice. The uterine receptivity after treatment was assessed by examining cell proliferation in the uterine luminal epithelium (LE). The gene expressions in the endometrium were investigated by RNA-seq. The p<0.05 was considered significant. Results: Cell proliferation in the LE ceased only when the window of implantation was open. Estrogen (E2) stimulated cell proliferation in the LE rendered the uterus refractory. The high throughput gene expression analysis by RNA-Seq showed that the insulin-like growth factor 1 (IGF1) pathway was the candidate to close the implantation window under E2. In vivo administration of IGF1 to delayed implantation mice resulted in proliferation in the LE cells. Conclusion: This study demonstrated that the window of uterine receptivity was closed by E2, which was mediated by the IGF1 pathway.
Keywords

  1. Wang H, Dey SK. Roadmap to embryo implantation: clues from mouse models. Nat Rev Genet. 2006;7(3):185-99.
  2. Macklon NS, Geraedts JP, Fauser BC. Conception to ongoing pregnancy: the 'black box' of early pregnancy loss. Hum Reprod Update. 2002;8(4):333-43.
  3. Diedrich K, Fauser BC, Devroey P, Griesinger G; Evian Annual Reproduction (EVAR) Workshop Group. The role of the endometrium and embryo in human implantation. Hum Reprod Update. 2007;13(4):365-77.
  4. Cheong Y, Boomsma C, Heijnen C, Macklon N. Uterine secretomics: a window on the maternal-embryo interface. Fertil Steril. 2013;99(4):1093-9.
  5. Paria BC, Huet-Hudson YM, Dey SK. Blastocyst's state of activity determines the "window" of implantation in the re-ceptive mouse uterus. Proc Natl Acad Sci USA. 1993;90(21):10159-62.
  6. Li Q, Kannan A, DeMayo FJ, Lydon JP, Cooke PS, Yamagishi H, et al. The antiproliferative action of progesterone in uterine epithelium is mediated by Hand2. Science. 2011;331(6019):912-6.
  7. Lee K, Jeong J, Kwak I, Yu CT, Lanske B, Soe-giarto DW, et al. Indian hedgehog is a major mediator of progesterone signaling in the mouse uterus. Nat Genet. 2006;38(10):1204-9.
  8. Kurihara I, Lee DK, Petit FG, Jeong J, Lee K, Ly-don JP, et al. COUP-TFII mediates progesterone re-gulation of uterine implantation by controlling ER activity. PLoS Genet. 2007;3(6):e102.
  9. Large MJ, DeMayo FJ. The regulation of embryo implantation and endometrial decidualization by progesterone recep-tor signaling. Mol Cell Endo-crinol. 2012;358(2):155-65.
  10. McCormack JT, Greenwald GS. Evidence for a preimplantation rise in oestradiol-17beta levels on day 4 of pregnancy in the mouse. J Reprod Fertil. 1974;41(2):297-301.
  11. Chen JR, Cheng JG, Shatzer T, Sewell L, Hernandez L, Stewart CL. Leukemia inhibitory factor can substitute for nidatory estrogen and is essential to inducing a receptive uterus for implantation but is not essential for subsequent em-bryogenesis. Endocrinology. 2000;141(12):4365-72.
  12. Terakawa J, Wakitani S, Sugiyama M, Inoue N, Ohmori Y, Kiso Y, et al. Embryo implantation is blocked by intraperitoneal injection with anti-LIF antibody in mice. J Reprod Dev. 2011;57(6):700-7.
  13. Terakawa J, Watanabe T, Obara R, Sugiyama M, Inoue N, Ohmori Y, et al. The complete control of murine pregnancy from embryo implantation to parturition. Reproduction. 2012;143(3):411-5.
  14. Daikoku T, Cha J, Sun X, Tranguch S, Xie H, Fujita T, et al. Conditional deletion of Msx homeobox genes in the uterus inhibits blastocyst implantation by altering uterine receptivity. Dev Cell. 2011;21(6):1014-25.
  15. Ma WG, Song H, Das SK, Paria BC, Dey SK. Estrogen is a critical determinant that specifies the duration of the window of uterine receptivity for implantation. Proc Natl Acad Sci USA. 2003;100(5):2963-8.
  16. Diao H, Paria BC, Xiao S, Ye X. Temporal expression pattern of progesterone receptor in the uterine luminal epithelium suggests its requirement during early events of implantation. Fertil Steril. 2011;95(6):2087-93.
  17. Zhu L, Pollard JW. Estradiol-17beta regulates mouse uterine epithelial cell proliferation through insulin-like growth factor 1 signaling. Proc Natl Acad Sci USA. 2007;104(40):15847-51.
  18. Rizzino A, Kazakoff P, Ruff E, Kuszynski C, Ne-belsick J. Regulatory effects of cell density on the binding of trans-forming growth factor beta, epidermal growth factor, platelet-derived growth factor, and fibroblast growth factor. Can-cer Res. 1988;48(15):4266-71.
  19. Naruo K, Seko C, Kuroshima K, Matsutani E, Sasada R, Kondo T, et al. Novel secretory heparin-binding factors from human glioma cells (glia-activating factors) involved in glial cell growth. Purification and biological properties. J Biol Chem. 1993;268(4):2857-64.
  20. Laron Z, Anin S, Klipper-Aurbach Y, Klinger B. Effects of insulin-like growth factor on linear growth, head circumfer-ence, and body fat in patients with Laron-type dwarfism. Lancet. 1992;339(8804):1258-61.
  21. Dey SK, Lim H, Das SK, Reese J, Paria BC, Dai-koku T, Wang H. Molecular cues to implantation. Endocr Rev. 2004;25(3):341-73.
  22. Nelson JF, Karelus K, Felicio LS, Johnson TE. Genetic influences on oestrous cyclicity in mice: evidence that cycle length and frequency are differentially regulated. J Reprod Fertil. 1992;94(1):261-8.
  23. Shaikh A, Abraham GE. Measurement of estrogen surge during pseudopregnancy in rats by radioimmunoassay. Biol Reprod. 1969;1(4):378-80.
  24. Pepe GJ, Rothchild I. A comparative study of serum progesterone levels in pregnancy and in various types of pseudopregnancy in the rat. Endocrinology. 1974;95(1):275-9.
  25. Saito TR, Kosaka T, Takahashi KW. Plasma progesterone levels in pseudopregnant mice. Nihon Juigaku Zasshi. 1982;44(1):125-6.
  26. Wakuda K, Takakura K, Nakanishi K, Kita N, Shi H, Hirose M, et al. Embryo-dependent induction of embryo receptiv-ity in the mouse endometrium. J Reprod Fertil. 1999;115(2):315-24.
  27. Das A, Mantena SR, Kannan A, Evans DB, Bagchi MK, Bagchi IC. De novo synthesis of estrogen in pregnant uterus is critical for stromal decidualiz-ation and angiogenesis. Proc Natl Acad Sci USA. 2009;106(30):12542-7.
  28. Cooke PS, Buchanan DL, Young P, Setiawan T, Brody J, Korach KS, et al. Stromal estrogen receptors mediate mitogenic effects of estradiol on uterine epithelium. Proc Natl Acad Sci USA. 1997;94(12):6535-40.
  29. Richards RG, Walker MP, Sebastian J, DiAugu-stine RP. Insulin-like growth factor-1 (IGF-1) receptor-insulin receptor substrate complexes in the uterus. Altered signaling response to estradiol in the IGF-1(m/m) mouse. J Biol Chem. 1998;273(19):11962-9.
  30. Kapur S, Tamada H, Dey SK, Andrews GK. Expression of insulin-like growth factor-I (IGF-I) and its receptor in the peri-implantation mouse uterus, and cell-specific regulation of IGF-I gene expression by estradiol and progesterone. Biol Reprod. 1992;46(2):208-19.
  31. Murphy LJ, Murphy LC, Friesen HG. Estrogen induces insulin-like growth factor-I expression in the rat uterus. Mol Endocrinol. 1987;1(7):445-50.
  32. Contreras PC, Steffler C, Yu E, Callison K, Stong D, Vaught JL. Systemic administration of rhIGF-I enhanced regener-ation after sciatic nerve crush in mice. J Pharmacol Exp Ther. 1995;274(3):1443-9.
  33. Mehls O, Irzynjec T, Ritz E, Eden S, KovĂ cs G, Klaus G, et al. Effects of rhGH and rhIGF-1 on renal growth and mor-phology. Kidney Int. 1993;44(6):1251-8.
  34. Hewitt SC, Li Y, Li L, Korach KS. Estrogen-mediated regulation of Igf1 transcription and uterine growth involves direct binding of estrogen receptor alpha to estrogen-responsive elements. J Biol Chem. 2010;285(4):2676-85.
  35. Silha JV, Murphy LJ. Insights from insulin-like growth factor binding protein transgenic mice. Endocrinology. 2002;143(10):3711-4.
  36. Sherwin JR, Freeman TC, Stephens RJ, Kimber S, Smith AG, Chambers I, et al. Identification of genes regulated by leukemia-inhibitory factor in the mouse uterus at the time of implantation. Mol Endocrinol. 2004;18(9):2185-95.
  37. De Mellow JS, Baxter RC. Growth hormone-de-pendent insulin-like growth factor (IGF) binding protein both inhibits and potentiates IGF-I-stimu-lated DNA synthesis in human skin fibroblasts. Biochem Biophys Res Commun. 1988;156(1):199-204.
  38. Conover CA. Potentiation of insulin-like growth factor (IGF) action by IGF-binding protein-3: studies of underlying mechanism. Endocrinology. 1992;130(6):3191-9.
